PANEL | 24"DLED TV |
Panel supplier | CMO/ BOE Optional |
Resolution | HD 1366*768 |
Response Time (typical) | 6.5ms |
Back Light | LED |
Brightness(cd/m2)(typical) | 200±10cd/m² |
Contrast Ratio(typical) | 3000:1 |
Viewing Angle Degree(L/R/U/D) | 89/89/89/89(CR≥10) |
Frame Rate | 60Hz |
Aspect Ratio | 16:9 |
Display Colors | 16.7M |
Panel Spec | A grade |
BROADCASTING |
|
Tuner System | Analog |
Tuner Receiving Range 48.25MHz ~ 863.25MHz |
Input impedance 75Ω |
PICTURE |
|
Color Temperature | Normal/Warm/Cool |
Scaler Mode | 4:3, 16:9, zoom, Just Scan, Full |
Picture Effect | 4 picture effects preset (Dynamic/Standard/Mild/User) |
Comb Filter | 3D |
DEINTERLACE | 3D |
Blue Stretch | YES |
Motion Compensation | YES |
Black Stretch | YES |
DLTI | YES |
DCTI | YES |
Noise Reduction | YES |
AUDIO |
|
Audio Output | 2 X 5W (big magnet speaker) |
Sound Effect | Standard, Music, Movie, Sprots, User |
Sound Control | Balance,Sound EQ Adjust |
INPUTS AND OUTPUTS |
|
HDMI(HDCP) Input | x1(Rear) |
CVBS In | x2(Rear) |
Earphone | x1(Rear) |
VGA | x1(Rear) |
PC Audio in | x1(Rear) |
USB Port | x1(Side) |
RF | x1(Side) |
POWER CONSUMPTION |
|
Power Supply | Build-in Power 100V-240V,60/50Hz (AC) |
35W |
Standby Power Consumption | <0.5W |
REMOTE |
|
Remote Control Type | Standard |
IR/RF | IR |
FUNCTION |
|
OSD Language | Lanuages Optional |
OSD Features | Motion Bmp Style |
Source in OSD | Source Bmp Icon Selecting |
Teletext | Optional |
Clock/Sleep Timers | Yes |
Wake up/Turn off time | Yes |
Wake up Source/Chanel | Yes |
Watch Time Limit | Yes |
Startup Setting | NO |
Smart Switch(AIS) | NO |
Dobly | Optional |
Picture Freeze | NO |
USB Connection | Movie Show:Support H.264、mpg、avi、mov / mkv、VOB |
MPEG4、MPEG2; |
Photo Show: Suppor JPEG、BMP、PNG; |
Music Show: support MP3、WMA、AAC; |
BASIC INFO |
|
TV System | PAL/SECAM /NTSC |
Chassis | RD8503 |
Material (White) | Front Cover:Plastic; Big backlight cover:Plastic;Small Back cover: plastic; Base: Plastic |
Sleep Timer | YES |
Closed Captioning Display | NO |
V-Chip | NO |
Doly Digital | NO |
Default Color of Front Cabinet | Black |
Keyboard Position | Rear side |
Base Stand Detachable | Yes |
VESA mount | 100 x 100mm / M4 screw |
Carton Dimesnion | 595*100*390mm |
Loading quantity (40HQ) | 2979Units |
SIGNAL FORMAT CAPABILITY |
|
Component Video Format | Y,Pb/Cb,Pr/Cr:up to 1080P |
HDMI Video Format | up to 1080P |
PC Compatibility | Up to 1920*1080 |
